CAMPAGNOLO ZONDA DISC Tubeless Ready front wheel (Center Lock)

Réf. fabricant : WH17-ZOCDF2A
Visit CAMPAGNOLO ZONDA DISC Front Wheel with Tires (Center Lock) is a benchmark among aluminum wheels for disc brakes. Designed specifically for bikes with... Read more

Recommanded price: 346,00 €

279,90 €
279,90 €
View full details

Description

Visit CAMPAGNOLO ZONDA DISC Front Wheel with Tires (Center Lock) is a benchmark among aluminum wheels for disc brakes.

Designed specifically for bikes with disc brakes, its redesigned structure offers optimum responsiveness thanks to asymmetrical rims and hubs. Mega G3™. This design improves front-wheel stability in the face of braking torque and maximizes power transfer to the rear.

Its new asymmetrical profile (26-28 mm) ensures better balancing of spoke tensions between the transmission and braking sides. Milled machining reduces perimeter weight, making the wheel more responsive. The RDB™ - Rim Dynamic Balance system ensures perfect weight balance, while the Rim Dynamic Balance MoMag™ technology improves rigidity and lightness.

The 21 stainless steel spokes and geometry Mega-G3™ geometry geometry enhance stiffness and responsiveness, especially under heavy braking.

The Campagnolo Zonda Disc guarantees long-lasting performance and versatility.

Manufacturer's manual

Ref: 9307217101149

Informations techniques

┘GENERAL
Front axle dimension: 12x100mm
Internal width: 22mm
Height: 24/27mm
Disc: Center Lock
Weight: 1675g
Part Number : WH17-ZOCDF2A

┘JANTES
Rim height: 24/27mm
Rim material : Aluminum
Internal rim width: 22 mm
Details: Bright Label
Tires: Tubeless and Tubetype (2-WAY-FIT)

┘RAYONS
Spokes:
- 14 stainless steel spokes with 2/1.6/2 mm cross-section (left side - brake side)
- 7 stainless steel spokes with 2/1.6/2 mm cross-section (right-hand side)
Lacing: Mega-G3
Nipples: Aero Mo-Mag aluminum, self-locking, internal

┘MOYEU
Hub type: aluminum hub with oversized flanges
Hub width:100
Axle type: 12 mm aluminum through axle
Bearings : Steel, cone/cuvette

┘ ASSEMBLY & TECHNOLOGIES
► The Zonda Disc Brake Wheel is assembled entirely by hand by a specialized Campagnolo® worker and 100% controlled through an electronically controlled tool. This process guarantees the maximum performance and rock-solid reliability of all Campagnolo® wheels;
► Asymmetrical technology optimizes spoke tension balancing, improving symmetry, efficiency and responsiveness between transmission and braking ;
► RDB™ technology balances the weight of the valve with an opposing counterweight, ensuring smooth, stable rotation for improved performance;
► Thanks to MoMag™ technology, the hole-free external profile improves rigidity and reduces weight, optimizing wheel reliability and efficiency;;
► MEGA-G3™ technology enhances stiffness and responsiveness, stabilizing front braking and maximizing rear transmission, with a racing design ;

┘INCLUSIVE
User guide

Informations prix

Recommended retail price February 2024
