BMX INSPYRE Evo Disk Pro XL Grey 2026

Manufacturer ref.: VEIN2629
The BMX INSPYRE Evo Disk Pro XL 2026 is a BMX Race model designed to deliver a high level of performance on competition tracks.... Read more
799,90 €
799,90 €
View full details

Description

The BMX INSPYRE Evo Disk Pro XL 2026 is a BMX Race model designed to deliver a high level of performance on competition tracks. Its construction combines a Premium 6061-T6 aluminium frame, hydroformed tubes and a Triple Butted construction to achieve an excellent balance between stiffness, lightness and strength.

The Pro XL 21.25'' geometry is designed for riders looking for a fast and stable BMX during acceleration phases. The 3D forged Swell rear dropouts with integrated chain tensioners ensure precise rear wheel retention and make drivetrain adjustments easier.

The equipment is competition-oriented with a reliable drivetrain featuring a Forward Joyride AM 2-piece crankset, a 43-tooth aluminium chainring and a KMC Z-1 Narrow chain. The Alhonga hydraulic disc brake 140 mm provides precise control and power suited to the demands of modern BMX Race.

The build is completed by Forward Joyride double-wall aluminium wheels, Tioga Powerblock 20x1.75'' tyres and Inspyre Evo sealed bearing hubs. With an advertised weight of 9.34 kg, this BMX offers a high-performing, reliable package ready for both intensive training and competition.

Ref: 15995237532028

Technical information

Model: INSPYRE Evo Disk Pro XL 2026
Type: BMX Race
Size: Pro XL
Recommended rider size: approx. 1.70 m to 1.80 m
Frame: Inspyre Evo Disk Pro XL
Top tube size: 21.25''
Material: Premium 6061-T6 Aluminium
Construction: Hydroformed tubes
Technology: Triple Butted
Rear dropouts: 3D forged Swell
Chain tensioners: Integrated

Fork / Headset
Fork: Inspyre Evo
Material: 100% Chromoly
Steerer: 1-1/8''
Headset: Integrated tapered
Bearings: Sealed cartridge
Standards: IS42 / IS52

Cockpit
Handlebar: Inspyre Evo
Material: 100% CrMo
Diameter: 22.2 mm
Dimensions: 8'' x 28.5''
Rise: 8''
Back Sweep: 7°
Upsweep: 1.5°
Grips: Forward Lock On
Grip length: 130 mm
Material: Kraton
Stem: Forward Top Load
Material: 6061-T6 Aluminium
Length: 50 mm
Diameter: 22.2 mm

Braking
Brake lever: Alhonga short lever
Calliper: Alhonga hydraulic
Disc: Forward Joyride AM
Disc diameter: 140 mm
Mounting: ISO 6-bolt

Drivetrain
Bottom bracket: External BSA
Bearings: Sealed
Crankset: Forward Joyride AM
Type: 2-piece
Fixing: 4-bolt
Crank length: 175 mm
Chainring: Aluminium
Number of teeth: 43T
Sprocket: Chromoly 16T
Chain: KMC Z-1 Narrow
Chain standard: 1/2'' x 3/32''

Wheels / Tyres
Front rim: Forward Joyride Aluminium
Rear rim: Forward Joyride Aluminium
Construction: Double wall
Number of holes: 36H
Front tyre: Tioga Powerblock 20x1.75''
Rear tyre: Tioga Powerblock 20x1.75''
Front hub: Inspyre Evo Aluminium
Front axle: 10 mm
Bearings: 100% sealed
Rear hub: Inspyre Evo Disc Aluminium cassette
Rear axle: 10 mm
Engagement: 120 points
System: 3 pawls
Spokes: 14G stainless steel
Nipples: 14G brass

Saddle: Saddle + seatpost combo
Seatpost material: Nylon
Seatpost diameter: 27.2 mm
Saddle clamp: Forward AM
Diameter: 31.8 mm

Stated weight: 9.34 kg
;
