CANE CREEK HELM MKII Coil 29"/27.5+ Tapered Thru-Axle 15x110 mm Boost Black Fork

Famous for its headsets and shock absorbers, CANE CREEK confirms its place in the suspension market MTB with its Helm MKII fork, designed forEnduro... Read more
Regular price 1.099,90 €
Regular price Sale price 1.099,90 €
View full details

Description

Famous for its headsets and shock absorbers, CANE CREEK confirms its place in the suspension market MTB with its Helm MKII fork, designed forEnduro ! This fork designed for 29-inch or 27.5 wheels+ features an adjustable travel using 160 mm shims in a version with Coil spring ( also adjustable to the rider's weight ).

This MKII evolution incorporates a new cartridge to increase support and control with a new compression and mid-valve and provides better support thanks to a new oil Motorex of 2.5.

In addition to an easily adjustable travel, this fork features a shock absorber adjustable in high/low-speed compression and low-speed rebound. As for the coil spring, it provides great comfort on fast descents and jumps thanks to its linear and supple damping.

Equipped with 35 mm stanchions, this CANE CREEK fork features the brand's patented D-Loc axle D-Loc patented by the brand, whose unique design best manages the rotational forces to which the fork components are subjected. It also features SKF seals low friction for superior sensitivity.

Ref: 9259156668765

Points forts

Coil spring adjustable to rider weight

Adjustable travel thanks to the supplied spacers

SKF low-friction seals

Numerous adjustment possibilities

The patented D-Loc Boost axle.

Informations techniques

Discipline: Enduro/All Mountain
T: Single
Wheel Sizes: 29"/27.5+
Front Wheel Axle: 15x110 mm (Boost)
Lockout: None
Colour: Black
Travel: 160 mm
Variable Travel: Yes with supplied spacers
Offset: 51 mm
Max Disc Diameter: 200 mm
Min Disc Diameter: 180 mm
Steerer Diameter: Tapered 1.5"-1"1/8
Stanchion Diameter: 35 mm
Brake Mount: Postmount
Fork Height:
573 mm at 160
Steerer Length: 265 mm (cuttable)
Steerer Material: Aluminium
Stanchions: Aluminium
Lowers: Magnesium
Adjustable Air Volume: No
Spring: Coil

Adjustable coil spring:
AAG0421 Red – for riders from 40 to 55kg
AAG0422 Black – for riders from 55 to 73kg
AAG0424 Green – for riders from 73 to 90kg = spring installed as standard
AAG0426 Blue – for riders from 90 to 110kg
Adjustable travel with supplied spacers 8 positions
SKF dust and oil seal
D-Loc axle in Boost format

Low Speed Compression Adjustment: 17 positions
High Speed Compression Adjustment: 10 positions
Low Speed Rebound Adjustment: 10 positions
High Speed Rebound Adjustment: No
Preload Adjustment: Yes

Tyre compatibility: up to 2.5" width in 29" and 2.8" in 27.5+

Manufacturer weight: 2340g
Manufacturer reference:
BAG0678

Informations prix

*Supplier recommended retail price in February 2024
