DT SWISS A 1800 SPLINE 30 DISC Tubeless Ready Rear Wheel (Center Lock)

The DT SWISS A 1800 SPLINE 30 rear wheel has been designed to deliver maximum efficiency and reliability in a highly aerodynamic package. Its... Read more
219,90 €
219,90 €
View full details

Description

The DT SWISS A 1800 SPLINE 30 rear wheel has been designed to deliver maximum efficiency and reliability in a highly aerodynamic package. Its 30 mm aluminium rim benefits from a wind-tunnel-developed profile to reduce air resistance and improve the overall efficiency of the bike. Combined with hidden nuts and components specifically selected for their aerodynamic efficiency, it enables you to gain speed while maintaining excellent versatility.

The heart of the wheel is built around the robust DT Swiss 370 hub, now equipped with the Ratchet LN 18 system. This technology ensures simultaneous engagement of the freehub mechanism teeth, guaranteeing reliable and durable power transfer during accelerations. The Ratchet LN design is recognised for its longevity and its ability to withstand intensive use, both in training and amateur competition.

The DT Aero Comp Wide Straightpull spokes complete the package by providing stiffness, precision and aerodynamic performance. Compatible with Tubeless Ready, the A 1800 SPLINE 30 rear wheel is a high-performing solution for cyclists looking to enter the world of DT Swiss aerodynamic wheels at an excellent price-to-performance ratio.

Manufacturer Manual + Rim/Tyre Compatibility & Pressure Chart

SPLINE Models Manual

Tubeless Fitting Manual

Ref: 7967884542118

Informations techniques

┘GENERAL
Category: Road
Manufacturer Weight: 964 g
Max Load: 110 kg
ASTM Classification: 1
E-Bikes Recommended: No
Manufacturer Reference: W0A1800NIDMSA20790

┘RIM
Material: Aluminium
Tyre Interface: Hooked/Crochet tubeless TC
Wheel Diameter: 622mm / 29" / 700c
Rim Height: 30mm
Internal Width: 20mm
External Width: 24mm

┘HUBS
Axle System: 12mm Thru axle
Spacing: 142mm
Disc Mount: Center Lock
Freehub Body: Shimano HG
Freehub: Ratchet LN 18
Hub Type: 370

┘SPOKES AND NIPPLES
Number: 24
Left spokes: DT aero comp® t-head
Right spokes: DT aero comp® t-head
Lacing type: Two-cross (1:1)
Nipples: DT Pro Lock hidden aluminum

┘ASSEMBLY & TECHNOLOGIES
► AERO RANGE: The DT Swiss Aero range maximises aerodynamics with profiled rims and innovative spokes, offering high performance and exceptional stability, ideal for reaching optimal speeds;
► SPLINE: The DT Swiss SPLINE concept combines robust hubs, optimised straight-pull spokes and Ratchet technology for efficient power transfer. It ensures reliability, responsiveness and ease of maintenance for versatile performance;
► AERO+: DT Swiss Aero+ technology optimises aerodynamics and stability by reducing drag and improving manoeuvrability. It perfectly balances air resistance, pedalling efficiency and crosswind control;
► RATCHET: DT Swiss Ratchet freehub technology ensures fast and precise engagement thanks to its high-precision ratchet ring system. It guarantees efficient power transmission, high reliability and minimal maintenance;
► ARTISAN KNOW-HOW: Hand-built, guaranteed to benefit from all of DT Swiss's expertise;

┘INCLUDED
Rim tape: Tubeless strip 23mm
Valve: TL alu black valve 26-35 mm / Valve protection sticker

┘CONVERSION REFERENCES
► Adapters for Shimano HG / QR: HWGXXX0006383S;
► XDR / QR Kit: HWYABM00S5716S;
► XDR / 12x142 Kit: HWYABX00S7711S;
► Adapters for XDR / QR: HWGXXX00S5483S;
► Microspline / 12x142 Kit: HWYABM00S1962S;
► Adapters for Microspline / QR: HWGXXX00S5623S;
► Campagnolo N3W / 12x142 Kit: HWYABM00S0692S;
► Adapters for DT Swiss Thru Bolt System: HWGXXX0006560S;
► Adapters for Shimano HG / 12x135: HWGXXX0007569S;
;

Informations prix

*Recommended retail price from supplier in June 2026
