HOPE UNION GRAVITY Pedals Black

Réf. fabricant : PDUGCN
The construction of the Hope Union Gravity GC pedal is ultra-robust, with a shape designed for maximum strength and grip. The 7 replaceable and... Read more
184,90 €
184,90 €
View full details

Description

The construction of the Hope Union Gravity GC pedal is ultra-robust, with a shape designed for maximum strength and grip. The 7 replaceable and adjustable pins per face are sturdy and easily interchangeable even when damaged.

They operate using cleats and a dual stainless steel engagement mechanism that reduces the effort required to clip in, providing a firmer hold and quick release.

Their durability over time is ensured by the multiplication of sealed ring bearings, which admirably distributes the applied load.

Fully repairable

Download the technical documentation here

Ref: 8083215417510

Points forts

Fully CNC-machined aluminium body ;

Dual engagement mechanism for greater ease and safety ;

14 pins per pedal ;

Two sets of cleats included ;

Fully maintainable and repairable.

Caractéristiques

Cleats Included : Yes

Warranty : 2 years

Axle Material : Chromoly Steel

Platform Material : Aluminium

Adjustable Spring Tension : Yes

Pedal Type : Clipless

Bearing Type : Annular

Informations techniques

CNC machined robust body in T6 2014 Aluminium ;
Chromoly Steel axle with high-resistance heat treatment ;
7 screw-in pins per side, 14 per pedal ;
3 annular bearings + 1 Norglide bushing for reduced maintenance and excellent reliability ;
8 platform shims + 8 platform spacers ;
2 sets of cleats:
N°4 - Angular float 4° - release at 12° - Lateral float 2mm ;
N°5 - Angular float 5° - release at 13° - Lateral float 2mm ;
4 cleat shims: 2x0.5 mm + 2x1 mm ;
2 cleat plates ;
Fitting gauge ;
Weight (manufacturer): 498 g.
;

Informations prix

*Supplier recommended retail price in February 2024
